Handheld oscilloscopes automotive in comparison

Powerful software Friendly UI FFT or X-Y, and waveform 2 views displayed on the same screen, practical features, make testing easier.

FAST SAMPLING RATE The DSO152 mini oscilloscope has a real-time sampling rate of 2.5MS s, with a bandwidth of 200KHz. It can measure voltages up to 800VPP with a 10x probe, equivalent to 280VAC. Whether it's periodic analog signals or non-periodic digital signals, users can freely use it, with the ability to measure voltage signals up to 400V.

CLEAR DISPLAY The digital oscillograph has a compact size with a 2.8in screen, which is clear and intuitive, greatly improving measurement efficiency.

Data Saving & Exporting Built in 3000mah rechargeable lithium battery, It can work continuously for 6 hours after being fully charged. Economical oscilloscope supports export + saving and viewing of waveform screenshots to facilitate you to conduct data analysis again. Allowing you towork outdoors without being limited by the site.

High-Performance Measurement 200kHz bandwidth with 2.5 MS s real-time sampling rate ensures precise waveform capture. Supports single auto normal trigger modes for stable signal analysis.

The DSO152 mini oscilloscope has a real-time sampling rate of 2.5MS s and a bandwidth of 200KHz. The 10x probe can measure up to 800VPP, which is equivalent to 280V AC. Voltages up to 400V can be measured.

Interface Display Oscilloscope mode is a complete intelligent measurement system which includes signal input, data sampling, data processing and automatic search, with the waveform test bandwidth of 500KHZ. With a variable sampling frequency, the slowly varying signal amount can be measured.. It is applicable to measuring and observing various signals on the automobile circuit during the car overhaul.

User-Friendly Oscilloscope The protable handheld oscilloscope is equipped with a 4.3 inch high definition touch screen, 8 languages can be switched at will, 3 different triggering modes (AUTO NORMAL SINGLE) for users to choose, and a powerful waveform image manager supports thumbnail browsing, viewing, detailed viewing, page flipping, deleting, and waveforms to zoom in, zoom out, and move around, and other functions.

Double Mode DSO153 adopts oscilloscope and DDS signal generator double mode. It is not only upgraded to 1MHz Bandwidth, 5MS s Sampling Rate, 500ns-20S time base range, but with the 10X prode comes with the package, voltages up to 400V can be measured.

Newly Version The 2C53T is an upgraded version of the 2C23T, which improves the measuring range and adds math operation cursor measurement persistence mode XY mode features.

Data of Digital Oscilloscope The Handheld Oscilloscopes is capable of manually adjusting parameters. It is also capable of automatic measurements, recognising uncertain waveforms, automatically adjusting amplitude and time base, and matching waveforms. It also has a vertical system to set the waveform voltage amplitude, scale size, and position.

Storage and Sampling Rate This oscilloscope features 20K storage depth with waveform compression and expansion capabilities; Dual channels design, 50M per channel sampling rate
