4 channel digital oscilloscopes in comparison

Faster Sampling Speed The DSO152 mini oscilloscope has a real-time sampling rate of 2.5MS s and a bandwidth of 200KHz. The 10x probe can measure up to 800VPP, which is equivalent to 280V AC. Voltages up to 400V can be measured.

Professional Measurement Digital Oscilloscope has dual-channel 2x100MHz bandwidth, 1GSa s real-time sampling rate, complete trigger function (single normal auto) and efficient one-button AUTO. Built-in 6000MAH rechargeable battery, full charge can be used for 4 hours.

Trigger Mode This oscilloscope has multiple trigger modes, supporting positive and negative edge trigger, logic trigger, and pulse width trigger.Oscilloscope code application layer is open source, and users can develop oscilloscope firmware according to their needs.

4-in-1 Handheld Oscilloscope this dual-channel 25MHz digital oscilloscope is a full-featured and highly practical oscilloscope, multimeter, flexible current clamp, and signal generator in one. The oscilloscope multimeter has one-key switching mode, automatic waveform acquisition, time base calibration, data storage, data export, data transfer port, 7 waveform outputs, afterglow time, memory and other functions, which are easy to operate and improve work efficiency.

Due to different batches, there may be differences in product appearance, color, and printed text, which not affect the use.

Superior Rate With an industry-leading 700,000 waveforms per second rate, this device effectively catches transient anomalies for thorough analysis and detection of signal events.

The USB Type-C interface supports not only mobile power supply but also adapter charging. With ultra-low power consumption of less than 3W, it can operate continuously for about 6 hours. Supports computer connection. When connected to a computer, the oscilloscope is recognized as a USB flash drive and can read stored images and CSV waveforms, which is convenient for displaying and analyzing future waveforms and sharing waveform data.

ALL-IN-ONE FUNCTIONALITY The DPOS350P combines a oscilloscope, a signal generator, a spectrum analyzer, and a frequency response analyzer to fulfill diverse signal testing requirements.

Specifications DHO814 digital oscilloscope bandwidth of 100MHz, sampling rate of 1.25G Sa s, storage depth of 25Mpts, 4-channel oscilloscope, time base range of 5 ns div 500 s div vertical gear 500 V div 10 V div, waveform capture rate of 1,000,000 wfms s, 7-inch colour touch screen, the machine Size is 265.35 mm (L) 161.75 mm (H) 77.38 mm (W), weight 1.78Kg, is a portable digital oscilloscope.

Soft trigger type positive and negative edge trigger,pulse width trigger,logic trigger; Trigger mode automatic,standard,single, scan; Trigger Source CH_A CH_B CH_C CH_D

2+1 CH 3 in 1 multi-function oscilloscope, built-in 1CH waveform generator, portable oscilloscope convenient for your job. Owing accurate detection function, well triggering ability of waveform generators and useful oscilloscope and 20,000 count resolution DMM

8 Languages Supported The product supports 8 languages, making it accessible to users from different regions and backgrounds.
