Constrabo Wire Rope Clamp (5, 11 mm) - Silver

Constrabo Wire Rope Clamp (5, 11 mm) - Silver
Show on Amazon
Show on Amazon

Colour: Silver

Constrabo® | 5X Wire Rope Cable Clip Clamp DIN 741 | Size 10 mm | Wire Rope Clips Steel Galvanized | U Bolt Saddle Fastener, U-Clamps | Wire Rope Grips for Wire Ropes, Stainless Steel Ropes, etc.
Steel (Galvanized)
Constrabo Wire Rope Clamp (5, 11 mm) - Silver
Silver

Offer

amazon
£ 11.05
£ 4.49 | 1-2 Days
go to shop

Product description

  • Box contents you will receive 5 pieces of wire rope clamps in bow shape (clamp clamps) of the specified size for 10.5 mm to 11 mm wire ropes, stainless steel ropes, winch ropes, natural ropes, forestry ropes and other types of rope.
  • Size A 18.5 mm B 18.5 mm C 23 mm D M8 E 16.5 mm F 33.5 mm G 35 mm For illustration of the technical size details of the wire rope clamps see graphic! The size of the rope clamp should correspond to the thickness of the rope to be crimped up to max. 1.5 mm smaller. Our range at Constrabo also includes rope clamps in other sizes, as well as press clamps, press sleeves, wire rope thimbles and other wire rope accessories.
  • Material U-shaped shackle made of steel Q235 (galvanised) with M8 thread. Clamp (yok) made of carbon steel C45 (1.0503) also galvanised. Ideal for home, garden, hobby or even sailing. Shackle rope clamps are used as screwable connections for ropes. The rope clamp consists of a U-shaped screw (bracket), a yoke (clamping saddle or clamp) and two nuts. The ropes are placed in the U-screw and clamped with the help of the nuts.
  • Certification steel wire rope clamp according to DIN 741 tested quality. Are placed on rope connections safety requirements (e.g. Lifting loads, as a guy rope in construction, in elevators, etc.) should not be used. The rope clamps should only be used according to their technical parameters.
  • Use wire rope clamps are used to easily connect and secure wire ropes or to form a rope eye or loop on a wire rope (with or without thimble). Unlike press clamps, clamp clamps can be opened for readjustment and can also be reused. For the formation of a rope eye or a loop, corresponding shaping thimbles can be used. Matching DIN standard thimbles can be found as well as other products in our Amazon shop
